Robustel R1520 Global
Globally certified industrial Dual-SIM 4G/LTE router with 5ร LAN, GNSS, serial, DI/DO, and analog input for versatile field deployments.
The Robustel R1520 Global is an industrial LTE router for multi-site IoT connectivity, combining five Fast-Ethernet ports (configurable 1รWAN + 4รLAN), dual-SIM resilience, and Wi-Fi/Ethernet WAN options in a compact form factor. Security and remote operations are built in: IPsec, OpenVPN, GRE, WireGuard and DMVPN, plus RCMS for fleet monitoring, configuration and updates, and RobustVPN for fixed-IP access on any SIM.
For projects that span regions, the R1520 Global SKU consolidates wide LTE band coverage and a deep set of certifications (e.g., FCC/PTCRB, CE, RCM, ICASA, TDRA and more) to simplify procurement and deployment across markets.
Optional PoE-PD on ETH0 simplifies installation; DI/DO, analog input, and RS-232/RS-485 support common integration needs. The result: reliable, secure connectivity with a single platform that scales from local pilots to global rollouts.
DUAL-SIM CELLULAR
Global Frequency 4G/LTE, 3G & 2G with Dual-SIM Card support for failover
GLOBAL SKU
Optional Globally Certified SKU for simplified deployment in over 50 countries
INTERFACES
1x WAN, 4x LAN or 5x LAN,
1x RS-232, 1x RS-485, 1x DI/DO, 1x AI, GNSS
OPERATING SYSTEM
RobustOS – Lightweight Linux kernel with full SDK
RCMS ON-BOARD
RCMS Cloud device management enabled
R1520 Global ‘Quick Pitch’ Video
Example R1520 Global Use Cases
Heavy Equipment Fleets
Globally certified LTE router for heavy equipment fleets operating across regions. Delivers secure backhaul for telematics, diagnostics, and operator systems; dual-SIM failover helps maintain uptime as machines move between sites and countries; RCMS centralizes configuration, monitoring, and firmware updates across the fleet.
OEM Global Machinery
Globally certified LTE router for OEMs shipping industrial machinery worldwide without redesigning connectivity for each destination. Provides secure cellular WAN that works across regions, reducing reliance on local fixed networks and site-specific IT; dual-SIM resilience helps maintain uptime when carrier performance varies.
Global Retail & Branch Sites
Globally certified LTE router for global retail, branches, and distributed locations. Supports consistent deployment across countries with reliable primary or backup WAN; keeps POS and store operations online with dual-SIM resilience; enables standard templates and faster rollouts via RCMS, reducing local variation and support effort.
Looking for more use cases?
With millions of Robustel devices deployed across more than 100 countries, itโs impossible to capture every use case above. Explore the links below to discover some of the exciting and innovative ways our technology is making an impact worldwide.
This Device is RCMS Ready
RCMS is a cloud-based IoT device management platform that gives you real-time visibility across your entire Robustel fleet. So you can troubleshoot, update, and optimize performance from anywhere at anytime, without sending engineers to site.
Product Mounting Options
Desktop Mount
DIN Rail Mount
Wall Mount
System Architecture
|
Operating System |
RobustOS |
|
CPU |
MIPS, 650 MHz |
|
RAM |
128MB |
|
Flash |
16MB |
Cellular
|
Supported Technologies |
4G/LTE, 3G, 2G |
|
Antennas |
2 (MAIN + DIV) |
|
Connector |
SMA-K |
|
SIM |
2 x Mini SIM (2FF) |
Ethernet
|
Ethernet Ports |
5 x 10/100 Mbps, 5 x LAN by default, can be configured as 1 x WAN + 4 x LAN |
|
Magnet Isolation Protection |
1.5 KV |
PoE In (Optional)
|
PoE Ports |
WAN1 |
|
PoE Standards |
802.3af & 802.3at PD |
Serial Port
|
Serial Ports |
1 x RS-232 + 1 x RS-485 |
|
Connector |
2 x 4-pin 3.5 mm female socket |
|
Baud Rate |
300 bps – 115200 bps |
|
Signal Definition |
RS-232: RXD, TXD, SGND, RTS, CTS |
Digital Input/Output
|
DI/DO Ports |
1 x DI + 1 x DO (wet contact) |
|
Connector |
2 x 3-pin 3.5 mm female socket |
|
Isolation |
3 KV |
|
Absolute Maximum VDC |
+30 V DC (DI), +30 V DC (DO) |
|
Absolute Maximum ADC |
10 mA (DO) |
|
Signal Definition |
DI+, DI-, DO+, DO- |
Analog Input
|
Analog Ports |
1 x AI (can be configured as voltage type or current type) |
|
Connector |
2 x 3-pin 3.5 mm female socket |
|
Voltage Input Range |
0 ~ 24 V DC |
|
Current Input Range |
4 ~ 20 mA (current-type input requires external resistance, and finally measured by voltage) |
|
Signal Definition |
AI, AGND |
Wi-Fi
|
Wi-Fi Antennas |
2 (Wi-Fi 1 + Wi-Fi 2) |
|
Connector |
RP-SMA-K |
|
Standards |
802.11 b/g/n, supporting AP and Client modes |
|
Frequency Bands |
2.412 โ 2.472 GHz (2.4 GHz ISM band) |
|
Security |
WEP, WPA, WPA2, WPA3 |
|
Encryption |
64/128 AES, TKIP |
GNSS/GPS (Optional)
|
GNSS Antennas |
1 |
|
Connector |
SMA-K with 50 ohms impedance |
|
GNSS Technology |
GPS/QZSS/GOLNASS/Galileo/BeiDou |
|
Tracking sensitivity |
GNSS: greater than -148 dBm |
|
Horizontal position accuracy |
GNSS: 2.5 m |
Other Interfaces
|
Reset Button |
1 x RST |
|
LED Indicators |
1 x RUN, 1 x MDM, 1 x USR, 1 x WLAN, 1 x RSSI |
|
Watchdog |
Built-in |
|
RTC |
External RTC clock for accurate timekeeping Backup energy storage capacitor provides up to 2 days of maintenance |
|
USB |
1 x 480 Mbps High-speed USB 2.0 port (Type A, 5 V, 500 mA) |
Power Supply & Consumption
|
PSU Connector |
2-pin 3.5 mm female socket |
|
Input Voltage |
12/24 V DC, 9 ~ 36 V DC |
|
Power Consumption |
Idle: 3 W@12 V |
|
Recommended Power Supply |
12 V DC/1.5 A power adapter |
Physical Characteristics
|
Ingress Protection |
IP30 |
|
Housing & Weight |
Plastic, 250g |
|
Dimensions |
46 x 90 x 105 mm |
|
Installation Options |
Desktop, Wall Mount and 35mm DIN Rail |
|
Operating Temperature |
-25 – +70 ยฐC |
|
Storage Temperature |
-40 – +85 ยฐC |
|
Relative Humidity |
5 – 95% RH (non-condensing) |
Software Features
|
Network Protocols |
PPP, PPPoE, TCP, UDP, DHCP, ICMP, NAT, HTTP, HTTPs, DNS, NTP, SMTP, Telnet, ARP, VLAN, SSH2, DDNS, etc. |
|
VPN Tunnels |
IPsec, OpenVPN, GRE, WireGuard |
|
Firewalls |
DMZ, anti-DDoS, Filtering (IP/Domain name/MAC address), Port Mapping, Access Control |
|
Remote Management |
RCMS, Web, CLI, SMS |
|
Serial Port Protocols |
Transparent, TCP Client/Server, UDP, Modbus RTU to TCP |
|
SIM Management |
Smart Roaming |
|
Optional Apps |
L2TP, PPTP, DMVPN, VRRP, QoS, SNMP, Language, RCMS, Dynamic Route, Captive Portal, Modbus Master, TR069, Edge2Cloud, etc. |
Software Development Kit (SDK)
|
Supported Programming Languages |
C, C++ |
|
Flash available for SDK |
4MB |
|
RAM available for SDK |
64MB |
Regulatory and Type Approvals
|
Environmental |
RoHS 2.0, WEEE |
|
EMI |
EN 55032 Conducted Emission Class B |
|
EMS |
EN 61000-4-2 (ESD) Contact Level 2, Air Level 3 |
Available Models
|
Model |
Supported Frequency Bands |
Certifications |
Order Code |
Package Contents |
|
R1520-4L Global |
4G LTE FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B18/ B19/B20/B25/B26/B28 4G LTE TDD: B38/B39/B40/B41 3G: B1/B2/B4/B5/B6/B8/B19 2G: 850/900/1800/1900 MHz |
E-Mark, RCM, CE, UKCA, FCC, IC, |
A005600705 |
1 x R1520 Global Router (B Code: B056701) |
|
R1520-4L Global |
4G LTE FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B18/ B19/B20/B25/B26/B28 4G LTE TDD: B38/B39/B40/B41 3G: B1/B2/B4/B5/B6/B8/B19 2G: 850/900/1800/1900 MHz |
E-Mark, RCM, CE, UKCA, FCC, IC, |
A005600706 |
1 x R1520 Global Router (B Code: B056701) 1 x DIN Rail Mounting Kit 2 x Cellular Antenna 1 x Wi-Fi Antenna 1 x Power Adapter |
|
R1520-4L Global |
4G LTE FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B18/ B19/B20/B25/B26/B28 4G LTE TDD: B38/B39/B40/B41 3G: B1/B2/B4/B5/B6/B8/B19 2G: 850/900/1800/1900 MHz |
E-Mark, RCM, CE, UKCA, FCC, IC, |
A005600707 |
1 x R1520 Global Router (B Code: B056711) |
|
R1520-4L Global |
4G LTE FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B18/ B19/B20/B25/B26/B28 4G LTE TDD: B38/B39/B40/B41 3G: B1/B2/B4/B5/B6/B8/B19 2G: 850/900/1800/1900 MHz |
E-Mark, RCM, CE, UKCA, FCC, IC, |
A005600708 |
1 x R1520 Global Router (B Code: B056711) 1 x DIN Rail Mounting Kit 2 x Cellular Antenna 1 x Wi-Fi Antenna 1 x Power Adapter |
NOTE:
1. For more information about regional & carrier specific variants please contact us
